Specification
as following:： |
||
|
KXT E1200S
Medium size winding machine |
||
|
STYLE |
KXT E1200S-B
Manual |
KXT E1200S-C
Semi-automatic |
|
Producing
ability |
spiral
wound gasket with or without inner ring |
spiral
wound gasket with or without inner ring |
|
Special
function |
any
shape of SWG |
any shape of
SWG |
|
SWG
thickness |
4.5mm
(also suitable for 3.2mm,6.4mm and 7.2mm after changing roller parts, V shape
winding or W shape winding) |
4.5mm
(also suitable for 3.2mm,6.4mm and 7.2mm after changing roller parts, V shape
winding or W shape winding) |
|
Automatic
function |
/ |
PLC
size controlling, |
|
Maximum
gasket OD |
1000mm |
1000mm |
|
Minimum
gasket ID |
100mm |
100mm
|
|
Total
power |
2.2kw |
8kw |
|
Spindle
motor power |
1.5kw |
1.5kw |
|
welder
power |
/ |
6kw |
|
Frequency
Converter |
2.2G |
2.2G |
|
PLC |
/ |
xinjie |
|
Power
supply voltage |
380V/220V
for option, 3 phases |
380V/220V
for option, 3 phases |
|
linear
speed |
0-800mm/s |
0-800mm/s |
|
Air
compressor |
0.6—0.8
MPA |
0.6—0.8
MPA |
|
Machine
measurement |
1680*1500*920MM |
1680*1500*950MM |
|
Machine
net weight |
280
kg |
300
kg |
