Find Reliable Kammprofile Gaskets Manufacturers for Your Industrial Needs

Kammprofile gaskets represent a pinnacle of engineering for sealing solutions in demanding industrial applications. These are not your standard gaskets; they are a hybrid design that combines the flexibility of a soft filler material with the structural integrity and high load-bearing capacity of a profiled metal core. At Kaxite Sealing, we have refined this technology over decades, providing reliable, long-lasting seals for the most challenging environments, from offshore oil and gas platforms to high-pressure chemical processing plants.

The unique construction of a Kammprofile gasket is key to its performance. It features a solid metal core, typically made from stainless steel (grades 304, 316, 321), carbon steel, or exotic alloys like Titanium or Inconel. This core is precision-machined with a series of concentric "kamm" or comb-like profiles—ridges and grooves. A soft, conformable sealing layer, such as expanded Graphite (Flexible Graphite), PTFE, or ceramic fiber, is then laminated onto both sides of this profiled core. Under bolt load, the soft filler material flows into the grooves and micro-imperfections of the flange faces, creating an initial, low-stress seal. As internal pressure increases, it acts against the metal core, which prevents excessive compression and blow-out of the filler, maintaining seal integrity even under extreme thermal cycling, high pressure, and fatigue conditions.

Key Advantages of Kaxite Sealing Kammprofile Gaskets

• Exceptional Sealing Performance: Capable of sealing at very low bolt stresses, yet resilient enough for high-pressure applications up to 300 bar (4350 psi) and temperatures from cryogenic to over 1000°C (1832°F), depending on the filler material.
• Superior Flange Protection: The solid metal core distributes bolt load evenly, minimizing the risk of flange damage or distortion, unlike solid metal gaskets which can embed into softer flange materials.
• Excellent Recovery & Re-usability: The design offers good spring-back characteristics, allowing for some re-tightening and, in many cases, re-use, providing significant cost savings over time.
• Versatility: Suitable for a wide range of flange types, including raised face (RF), male-female (M&F), tongue-and-groove (T&G), and flat face flanges. They can also compensate for minor flange misalignment or surface imperfections.
• Material Compatibility: By selecting the appropriate metal core and filler combination, Kaxite Sealing can tailor gaskets for corrosion resistance, chemical compatibility, and specific operational parameters.

Detailed Product Parameters & Specifications

Selecting the correct Kammprofile gasket requires careful consideration of several parameters. At Kaxite Sealing, we manufacture to exact customer specifications and international standards.

Standard Material Combinations

*Temperature limit is filler-dependent. Graphite (inert atmosphere) can reach 1000°C+; with oxygen, limit is ~450°C.

Standard Profile Dimensions (Typical)

Standard Size & Pressure Class Ranges

• Inner Diameter (ID): From 15 mm (½") upwards, no practical upper limit.
• Outer Diameter (OD): Custom-cut to match flange dimensions exactly.
• Thickness: Standard metal core thicknesses: 1.5 mm, 2.0 mm, 3.0 mm. Overall gasket thickness depends on core + filler laminate.
• Pressure Classes: Suitable for ANSI classes 150 through 2500, PN 10 through PN 450, and custom high-pressure designs.
• Standards: Can be manufactured in accordance with ASME B16.20, DIN 2696, and customer drawings.

Kammprofile Gaskets - Frequently Asked Questions (FAQ)

Q: How do Kammprofile gaskets differ from spiral wound gaskets?
A: While both are composite gaskets, their core design and sealing mechanism differ significantly. Spiral wound gaskets use a V-shaped metal strip and filler wound together, offering good resilience but requiring higher bolt load to seal. Kammprofile gaskets have a solid, profiled metal core with laminated filler. They seal effectively at lower bolt loads, provide better flange protection due to the full-face solid core, and often exhibit superior performance in thermal cycling and high-pressure scenarios. Kaxite Sealing provides both types and can advise on the optimal choice for your application.

Q: Can Kammprofile gaskets be used on serrated flange faces?
A: Yes, they are exceptionally well-suited for serrated (phonographic) finish flanges. The soft filler material easily flows into the serration grooves, creating multiple intimate sealing barriers. The coarse profile type is often recommended for such surfaces to ensure optimal filler flow and engagement.

Q: Are they reusable?
A: Kammprofile gaskets from Kaxite Sealing are designed with reusability in mind. Their excellent recovery (spring-back) means they can often be re-used after a system shutdown, provided they are carefully inspected for any damage to the filler or metal core, the flanges are clean, and the original sealing conditions (pressure, temperature) remain the same. However, for critical service or if any doubt exists, replacement is always the safest practice.

Q: What is the recommended bolt torque for installing a Kammprofile gasket?
A: There is no universal torque value. The required bolt stress depends on the specific gasket design (profile, materials), internal pressure, and flange type. As a general rule, Kammprofile gaskets require significantly lower seating stress than solid metal gaskets but may need slightly higher than pure soft gaskets. Kaxite Sealing provides detailed installation guidelines and recommended bolt loads with every gasket order, calculated using industry standards like ASME PCC-1 or EN 1591. Always follow these specifications for a leak-free joint.

Q: How do I select the right filler material?
A: The filler selection is critical and depends on the process media, temperature, and pressure.

• Expanded Graphite (Flexible Graphite): Our most common filler. Excellent thermal conductivity, chemical resistance (except strong oxidizers), and sealing performance from cryogenic to high temperatures (in inert atmospheres).
• PTFE (Polytetrafluoroethylene): For extremely corrosive chemical services and cryogenics. Has temperature limitations (typically -200°C to +260°C).
• Ceramic Fiber (e.g., Kaowool): For very high-temperature applications exceeding the oxidation limits of graphite (above 450°C in air).
• Mica: Used in high-temperature, high-pressure steam applications and fire-safe scenarios.

Q: Can Kaxite Sealing supply Kammprofile gaskets with special features?
A: Absolutely. We specialize in custom-engineered sealing solutions. Common special features include:

• Inner or outer metal containment rings (guide rings) for alignment and to prevent filler erosion.
• Electro-polished or coated metal cores for ultra-clean or corrosive services.
• Non-standard profile geometries for unique pressure-holding requirements.
• Laser welding of the core seam for the highest integrity in nuclear or semiconductor applications.
• Complete gasket sets with aligned bolt holes for large heat exchangers or pressure vessels.
